Whatever kind of garment cloths users are trying to make ultra clear and precise line indication, not able to rely on any prior line drawing or printing work, it is making a better job to apply a highly intense and bright light emitted tool of a 515nm green laser line generator. Basically it keeps work with high sensitivity and easy absorbing green laser light directly from an import 515nm green laser diode, which is at least 5 times brighter than 650nm red light with the same output power. Under operation of correct use of output power and optic lens fan angle, this 515nm green line laser alignment still remains clear line indication even in bright workshops and under reflective fabrics. It always makes high precision line marking on garment cloths, maintaining excellent line straightness and narrow line width, noncontact and deformation free, ensuring strong consistency and significantly reducing cutting errors and rework.
From the very beginning design of a 515nm green laser line generator, it applies an import 515nm green laser diode within 50mW to 200mW as its beam emitting source. Only after it gets constant power source from an AC/DC adapter, there is no marking or templates required. It can greatly increase garment processing efficiency by 30%-50% and reduce fabric waste. Being made with a metal heat sink cooling system inside a durable anodized aluminum alloy housing tube, available with 16mm, 18.9mm and 26mm diameter design for different output power range, this green line laser alignment obtains superior nice heat dissipation, increasing stability and brightness green guidance indication for multiple garment processing works.
Equipped with APC, ACC driving circuit board, this glass coated lens made 515nm green laser line generator maintains continuous line projection and continuous operating lifetime of more than 8,000 hours. Available with wide fan angles of 10 to 110 degrees, it projects high linear quality and highly straight green reference line within 0.5 meter to 6 meters lengths. In addition, equipped with low beam divergence of less than 0.5mrad, the projected green line thickness can be adjusted within 0.3mm at 10cm, and 1mm to 2mm fineness at 2 meters distance. Within the long work distance of 25 meters, 515nm green line laser alignment is compatible with cotton, linen, synthetic fibers, leather, etc., without damaging the fabric, suitable for high-speed/automatic production lines.
Applications in garment making fields:
Cutting Bed Alignment: Projecting a linear line assists in the rapid alignment of multiple layers of fabric, preventing misalignment of patterns and stripes, suitable for positioning complex fabrics such as printed/checkered fabrics.
Fabric Cutting Machine Marking: Replacing chalk/rulers, providing a non-contact baseline. The cutter follows the light, with an error ≤0.3mm, suitable for reflective/dark fabrics.
Pocket Opening/Button Sealing: Projecting a precise linear line on pocket opening and button sealing machines to position pockets/buttons, reducing rework.
Sewing/Hemming Alignment: Projecting a straight line at flat seams and hemming stations to assist in consistent sewing/hemming trajectories, improving sewing and hemming accuracy.
Fabric Laying/Laying Guidance: Long-distance straight lines guide the fabric laying direction, ensuring parallelism between layers and improving laying efficiency and quality.
Category: alignment laser
Scientific Research Work of Glass Coated Lens 532nm Green Laser Diode Module
When 515nm wavelength laser diode is applied for the creation of a green laser diode module, it is always projecting the most sensitive green light to the naked eyes, with brightness far exceeding that of red and blue light at the same power. It applies an import 515nm green laser diode and a qualified optic lens inside a durable housing tube, which is also equipped with thermal emitting system. When green dot laser alignment gets constant electric power supply and proper installation or integration into scientific experimental device or equipment, it enables easy reaching, noncontact and highly precise green dot projection. It also remains clearly visible in both low-light and high-light experimental environments, facilitating experimental observation and real-time calibration, and reducing visual errors.
Being made with a qualified glass coated lens and glass window design in front of laser beam aperture, not affected by moisture, dust, rain, water or fog, this 515nm green laser diode module is keeping work with high transmittance and high photoelectric ability forest green light emission at long extending distance. When it gets highly powerful green light concentrated, it can convert into increasing accuracy and good round shape green dot projection in distance easily. It keeps work with stable energy output without drift, fully meeting the core requirements of scientific research experiments for ultra-precise positioning and light source stability, ensuring accurate experimental data. When 515nm green dot laser alignment gets low laser beam divergence, cooperated with adjustable focus optic lens, it is adopted to experimental needs of different precision and scenarios, featured by good light concentration, allowing for switching of working modes as needed, adapting to various experimental schemes.
Usually 515nm green laser diode module gets quite small size tube diameter, which is designed with 16mm, 18.9mm and 26mm diameter for different output power range of 50mW to 200mW. Within the lowest power consumption and low heat generation, it is allowing for flexible integration into various scientific instruments and experimental platforms. It is compatible with different brands of detection and observation equipment, and modification and debugging are convenient without interfering with the overall operation of the experimental device. Owing to its pure light output, 515nm green dot laser alignment causes no additional damage to experimental samples, and will not interfere with the acquisition of other experimental data such as spectral analysis and electrical signal acquisition, ensuring the purity and traceability of experimental results.
Applications in scientific research fields:
Core Applications in Optical Experiments: As a visible light reference source, 515nm green laser diode module is used for optical path calibration, performance testing of optical components, and is suitable for basic optical experiments such as laser transmission, interference, and diffraction. It can also assist in building optical measurement systems.
Physics Research Scenarios: In mechanics experiments, it serves as a reference point for calibrating object displacement and marking motion trajectories; in thermal and electrical experiments, it assists in precise equipment alignment; and it is a core excitation and detection auxiliary light source for quantum physics and optical sensing experiments.
Materials Science Research: It serves as a precise positioning point for material microstructure analysis and surface property testing. It assists electron microscopes, spectrometers, and other equipment in focusing the area to be tested; and it marks monitoring points in material modification and weather resistance testing to achieve long-term tracking observation.
Biology and Life Sciences: 515nm green alignment laser serves as a positioning marker for biological sample observation. It tracks points during microbial culture, which is suitable for microscopic observation and sample sampling positioning, with low power and no damage.
Application Advantages of 980nm Infrared Laser Line Generator In Industrial Inspection
What is a good solution for engineers and factory workers to make ultra clear and fine line indication for those of industrial inspection works? It is not workable at all to only rely on prior line drawing or printing work, not any longer limited by long distance, high height and other complex working environments etc, it always makes a good job to apply a long wavelength made device of a 980nm infrared line laser module. It is primarily used in industrial inspection for non contact line scanning, high precision dimensional measurement, detect or contour detection, and 3D reconstruction. Whenever it gets constant electric power source supply and proper use of output power and optic lens fan angles, this assistance part of IR laser line generator enables high precision, no visible interference and stable IR line projection for all online quality inspection works.
Unlike prior line drawing or printing work, the usual use of a 980nm infrared laser line generator gets no limitation by long distance, high height or other complex working environments as well. It applies an import 980nm infrared laser diode within 5mW to 500mW and high power up to 600mW to 1000mW. Being made with a metal heat sink cooling system inside a durable anodized aluminum alloy housing tube, it gets superior nice heat dissipation, and ultra stable infrared reference line projection in long term use. When IR laser line generator projects highly straight and fine infrared reference line, together with it small laser beam divergence fan angle of less than 2mrad. It is resulting in a positioning accuracy of ±0.1–±1mm, far superior to ordinary infrared LED line light sources, suitable for precision detection.
Configured with a glass window in front of laser beam aperture, 980nm infrared laser line generator can tolerate any harsh occasion of moisture, dust, rain, water or fog etc. 980nm is near infrared invisible light, resistant to sunlight and ambient light interference, and remains stable in outdoor/strong light environments. 980nm infrared laser light does not affect the human eye or visual systems, and there is no red glow. After its easy integration with any industrial inspecting machine or equipment, the infrared alignment laser line has high energy density, maintaining a stable line shape over distances of several meters to tens of meters, reducing transmission loss, and suitable for long distance line positioning and detection.
Applications in industrial inspections:
Surface and Contour Line Scanning: Detection of defects such as scratches, dents, bulges, and cracks in materials such as metal, plastic, and glass; measurement of flatness, edge straightness, width/thickness/gap of coils/sheets/films; achieving high-speed online inspection with infrared line scan cameras, uniform line width, and compatibility with continuous production lines.
High-Precision Dimensional and Gap Measurement: PCB/FPC board edge positioning, electronic component pin spacing/height measurement, mechanical part groove width/step difference detection; the line laser has a small divergence angle (typically ≤2mrad), a line width ≤1mm at 1 meter, and a positioning accuracy of **±0.1–±1mm**, replacing manual calipers/micrometers and improving efficiency by more than 10 times.
3D Contour and Volume Reconstruction: Based on the triangulation principle, used for 3D profilometers, industrial LiDAR, and volume/inventory scanning of material bins/shelves; compatible with AGV/AMR navigation, workpiece pose recognition, and glue/welding path guidance, quickly generating high-density point cloud data.
Special Material and Hidden Defect Detection: Photovoltaic cell PL imaging (hidden cracks, dirt, graphite boat marks), internal defect scanning of transparent plastics/dark metals, semiconductor wafer edge/chipping detection; the 980nm near-infrared light has strong penetration power, and can capture internal structural anomalies when combined with an infrared camera.
Equipment and Sensor Calibration: Infrared camera/line array detector field of view calibration, line laser sensor calibration, infrared optical system optical path debugging, providing a standard near-infrared light source to ensure detection consistency.
Advanced Adoption of 980nm Infrared Laser Diode Module for Biomedical Field
In any type of ultra clear and precise dot measurement for biomedical fields, a longer wavelength made device of 980nm infrared laser diode module enables excellent biocompatibility. The 980nm near-infrared band has extremely low irritation to normal human tissues and a moderate penetration depth, reaching target tissues of subcutaneous veins and deep muscles without easily causing tissue damage, ensuring high safety. Employed by an import 980nm infrared laser diode and a qualified optic lens inside a durable meta housing tube, only after its easy connects with an external electric power source supply, this direct diode emission made infrared dot laser alignment allows easy reaching, noncontact and no track infrared reference dot projection for multiple night version biomedical treatment fields conveniently.
In practical biomedical fields, the genuine use of a 980nm infrared laser diode module brings operators quite special use. It applies an import 980nm infrared laser diode within 5mW to 500mW and high power up to 600mW to 1000mW, equipped with a metal heat sink cooling system inside a durable anodized aluminum alloy housing tube, it enables long term lasted IR laser light generation in long term use. Owing to its superior nice heat dissipation, when infrared dot laser alignment makes constant infrared dot projection within 10 hours per day, it can maintains good laser beam stability, ultra long term lasted and precise infrared dot generation in long term use. Usually infrared light is completely invisible to the naked eyes, it does not produce dazzling strong light during use, does not affect the medical staff’s field of vision, and does not cause visual discomfort to patients, improving the comfort of diagnosis and treatment.
Configured with a qualified glass coated lens and adjustable focus optic lens designs in front of beam aperture, 980nm infrared laser diode module enables strong energy controllability. It allows high photoelectric ability and highly powerful infrared laser light emission, and converts into increasing accuracy and brightness infrared dot projection at a longer extending distance. According to the selection of different output power, it is matching different diagnostic and treatment scenarios as needed, offering excellent adaptability. Whenever 980nm infrared dot laser alignment gets highly concentrated IR laser light generation, it allows for targeted application to specific target areas, avoiding ineffective light radiation and ensuring the accuracy of diagnosis and treatment.
6.Whatever output power it is selected, this APC, ACC driving circuit board made device of 980nm infrared laser diode module enables stable output power with minimal fluctuation in light power output, ensuring accurate detection data and consistent therapeutic effects. Being made with compact structure and small size, this infrared alignment laser allows for easy integration into portable vein imaging devices, wearable health monitoring equipment, and small therapeutic devices, contributing to the miniaturization and portability of medical equipment.
Applications in biomedical fields:
1. Vein Imaging Assistance: As the core light source for vein imaging devices, infrared alignment laser light penetrates the skin surface, clearly outlining the contours of subcutaneous veins, assisting medical personnel in accurate venipuncture, suitable for outpatient blood collection and intravenous infusion.
2. Infrared Physiotherapy and Rehabilitation: Utilizing the 980nm infrared light thermal effect, it acts on local human tissues, promoting blood circulation and relieving muscle strain and joint pain, suitable for rehabilitation physiotherapy and pain management equipment.
3. Biological Tissue Detection: 980nm infrared laser diode module is used for infrared imaging of biological tissues and infrared characteristic analysis of pathological sections, assisting in lesion screening and tissue characteristic research, providing technical support for pathological diagnosis.
4. Non-invasive Health Monitoring: Integrated into non-invasive detection equipment, assisting in monitoring health indicators such as blood glucose, blood oxygen, and tissue water content, obtaining physiological data through the differences in absorption and reflection of infrared light by tissues.
5. Photobiomodulation Therapy: Low-power specifications are used for photobiomodulation, improving cell metabolism and promoting tissue repair, suitable for auxiliary treatment scenarios such as wound healing and mucosal repair.
6. Biomedical Research Experiments: 980nm infrared dot laser alignment is used for infrared response experiments of biological samples, non-invasive observation of living tissues, and infrared characteristic research of biological macromolecules (proteins, nucleic acids) in basic biomedical research.
Unique Use of 808nm Infrared Laser Diode Module for Industrial Processing Works
Whatever kind of working surface users are trying to make ultra clear and precise dot indication for those of industrial processing works, under operation of night version illumination work fields, it always makes an efficient job to apply a long wavelength made device of a 808nm infrared laser diode module. Compared to any other visible laser devices, owing to the adoption of a longer wavelength 808nm infrared laser diode, it projects invisible infrared laser beam and infrared reference dot from beam aperture. When infrared dot laser gets constant electric power source supply and proper equipment with night version device, it enables undisturbed IR laser dot alignment for all inspection works. It also assures low production cost, low thermal energy consumption and high precision infrared reference dot projection for all night version measuring fields conveniently.
Basically 808nm infrared laser diode module gets constant electric power source from an AC/DC adapter, after the acceptation of 100V to 240V operating voltage, it is working well with constant infrared laser beam emission from an IR laser diode within 5mW to 500mW and high power range of 600mW to 1000mW. For the most important of all, when it is used for long term lasted work, it gets advanced use of a metal heat sink cooling system inside a durable anodized aluminum alloy housing tube. Whenever infrared dot laser alignment gets superior nice heat dissipation, equipped with its low laser beam divergence, it is allowing for sub-millimeter positioning accuracy.
Unlike the visible laser devices, longer wavelength 808nm infrared laser diode module emits invisible IR laser light to the human eyes, thus it should only be working together with any night version device, such as a CCD camera, black and white camera or IR laser camera etc. It is applying a durable anodized aluminum alloy housing tube, which bears wide range operating temperature and mechanical moving or calibration. The near infrared laser light exhibits low attenuation in dusty and smoky environments, resisting strong light and electromagnetic interference, making it suitable for stable operation in harsh industrial conditions. Besides its operation of correct output power, infrared dot laser alignment allows proper adjustment of laser beam focus and IR dot emitting direction so as to achieve ideal dot aligning accuracy easily.
General applications in industrial processing works:
1. Precision Positioning and Tool Setting: 808m infrared laser diode module is used for tool setting and path calibration in machine tools, cutting machines, welding machines, etc. The dot-shaped IR laser spot provides precise positioning of the processing reference, suitable for metal/non-metal cutting, PCB assembly, woodworking machinery tool setting, and other scenarios.
2. Industrial Vision and Inspection: 808nm infrared alignment laser serves as infrared supplementary lighting and positioning markers in machine vision systems, assisting in the identification of part contours and surface defects. Suitable for automated sorting, 3D structured light inspection, and semiconductor wafer alignment.
3. Laser Pump Source: High-power laser modules are used to pump Nd:YAG and other solid-state lasers, providing high-energy laser output for metal welding, marking, and micromachining.
4. Material Modification and Curing: Precise irradiation achieves localized heating, used for 3D printing material curing, plastic welding, coating drying, etc., with a small heat-affected zone and high efficiency.
5. AGV and Robot Navigation: Provides infrared positioning points for industrial robots and AGVs, supporting SLAM navigation and precise docking, unaffected by strong light interference.
Reduced Production Cost Use of 660nm Red Line Laser Module in Textile Industry
What is an efficient job for garment makers to make ultra clear, fine and bright enough line indication for various garment cloth processing works? It is not easy to rely on primary manual line drawing or printing, but making even better job to apply a highly intense beam emitted tool of a 660nm red line laser module. It applies an import 660nm red laser diode and a qualified optic lens inside a different dimension metal housing tube. Cooperated with an external electric power source supply, after correct selection of both output power and optic lens fan angle, this laser line generator enables high red laser light visibility, ultra fine, clear and straight red reference line guidance onto multiple working surfaces conveniently.
Usually 660nm red line laser module applies an AC/DC adapter as its electric power source, not simply spending extra time on battery change, it is able to make continuous red laser light emission from an import 660nm red laser diode within 5mW to 500mW. In process of long term lasted red line generation, it is designed with a metal heat sink cooling system inside a durable anodized aluminum alloy housing tube, which enables superior nice heat dissipation and increasing stability red reference line projection within 10 hours per day. When laser line generator is pointing onto different color and pattern garment cloths, red reference line is still clearly visible under ambient lighting occasions, without bleed-through or residue, eliminating the need for repeated calibration.
When 660nm red line laser module applies a qualified glass coated lens within 10 to 110 degree fan angles, cooperated with adjustable focus optic lens in front of beam aperture, it is able to work with high straightness and high fineness red reference line projection. It enables controllable line thickness of only 1 to 2mm at 2 meters distance. Owing to its noncontact line indication, the whole process of garment cutting work can avoid cloth moving, reducing cut piece error, significantly lowering the scrap rate. Without spending extra time on manual line drawing or positioning work, this red line laser alignment enables conveniently installation, easy adjustment of red line thickness, and high speed line indication for multiple garment cloths processing works conveniently.
Applications in textile industry field:
Precise Cutting: 635nm red line laser module projects a baseline line onto the fabric laying machine/cutting table, replacing chalk/ink lines for quick alignment of patterns and stripes, and positioning of cut piece outlines.
Sewing Auxiliary Positioning: Uses a single-line alignment laser to mark seam positions, bag opening boundaries, and button centers on pocket opening machines, button attaching machines, and flat sewing machines, ensuring straight and uniform stitches.
Hemming/Ironing Guidance: Projects hemming lines onto ironing machines, guiding regular hemming of collars, cuffs, trouser hems, etc., ensuring consistent hemming width in batches and improving ironing neatness.
Sew/Assembly Calibration: Horizontal/vertical lines are projected during garment piece splicing and assembly to calibrate alignment and flatness, ensuring seamless and misaligned seams, such as shoulders and side seams.
Quality Inspection Assistance: Red laser line generator is marking dimensional baselines allows for quick comparison of garment dimensions, aiding in determining compliance with process standards and improving quality inspection efficiency.
Precise Machinery Processing with Gaussian Beam 635nm Red Laser Line Generator
Whatever kind of working surface users are not able to make ultra clear and precise line indication, in order to make sure of ideal accuracy measurement for all precise machinery processing works, it makes a good job to apply a pure light emitted tool of a 635nm red laser line generator. It applies an import 635nm red laser diode and a qualified optic lens inside a durable housing tube, and gets constant electric power source supply. Owing to its its pure and bright red laser light emission, together with its low beam divergence and special TEM00 laser beam mode, this red line laser module enables ultra fine, straight and bright red line indication in multiple operating workshop environments conveniently.
Commonly 635nm red laser line generator gets constant electric power source from a 5V, 9V, and 12V 1000mA AC/DC adapter, not spending extra time on prior line drawing or printing work, it always makes continuous red laser beam emission from its inner laser diode directly. For the most important of all, in order to make stable and clear line indication for other precise machinery processing works, it gets basic use of a metal heat sink cooling system inside a durable anodized aluminum alloy housing tube. Whenever red line laser module is applying for wide range operating temperature, mechanical moving or calibration etc, it still maintains high penetration red laser light generation, and converts into ultra fine and straight red line projection in multiple working environments. For instance, in machining workshops, it gets no effect by interference factors such as metal dust and coolant mist exist. 635nm red laser light has better penetration than short-wavelength lasers, ensuring clear visibility of positioning lines even under complex conditions.
Employed by an import 635nm red laser diode within 5mW to 100mW and high power up to 150mW to 500mW, cooperated with a qualified glass coated lens within 10 to 110 degree fan angles, 635nm red laser line generator is performing well with high metal surface recognition. Highly pure and bright red laser light exhibits high contrast on common metal surfaces, allowing for clear identification of positioning lines without the need for additional colorant spraying, simplifying the operation process. Whenever red line laser module gets correct use of output power and optic lens fan angle, unaffected by vibration, it still maintains stable and fine enough line projection, and also boasts low power consumption, long service life, and significantly lower maintenance costs compared to other wavelength laser modules. Featured by compact size structure design, it allows for flexible integration with CNC machining equipment and automated production lines. It supports linkage with equipment control systems for precise automated positioning guidance.
Applications in precise machinery processing:
1. Cutting and Positioning: 635nm red laser line generator is installed near the machining area of lathes, milling machines, and planers, the projected linear laser marks the workpiece’s machining reference line or the tool’s trajectory, assisting operators in quickly calibrating the workpiece’s clamping position and ensuring cutting dimensional accuracy.
2. Sheet Metal Bending Assistance: Projecting a linear line onto a bending machine precisely positions the bending line and angle of sheet metal, avoiding manual marking errors and improving the consistency of sheet metal bending. Suitable for batch processing scenarios such as chassis and cabinets.
3. Welding Alignment Guidance: Red alignment laser is used with welding equipment, the alignment laser line marks the position and width of the weld, assisting welders or automated welding arms in accurately aligning the weld bevel, reducing welding misalignment and incomplete welds.
4. Workpiece Assembly Calibration: In the component assembly process, using the linear laser as a reference, the relative position and perpendicularity of multiple parts are calibrated, ensuring the overall accuracy of the assembled machine. Suitable for precision machinery, mold assembly, and other assembly scenarios.
High Visibility 650nm Red Laser Diode Module For Industrial Processing Use
Whatever kind of working surfaces users are in need of seriously accurate and bright dot indication in those of industrial machinery processing works, not able to rely on any prior dot positioning work with any manual or mechanical dot aligning tool, it would be a much better solution to apply a highly bright and intense beam emitted tool of a 650nm red laser diode module. It applies an import 650nm red laser diode and a qualified optic lens inside a durable metal housing tube, the projected red laser light gets featured advantages of high red light visibility, clear visual recognition in normal temperature industrial environment. When red dot laser module makes correct use of output power and proper installation or integration into industrial machine or equipment, it enables ultra clear, no glare and no mistake dot measurement onto various working surfaces conveniently.
When dot measuring work is processing in various industrial machinery processing works, 650nm red laser diode module is required to generate different dimension red reference dot onto different working surfaces. It applies an import 650nm red laser diode within 5mW to 100mW and high power up to 150mW to 500mW as its beam emitting source. Usually it is designed with with an internal metal heat sink cooling system inside a durable anodized aluminum alloy housing tube, which is achieving superior nice heat dissipation and ultra stable red dot generation as long as 10 hours per day. Whatever output power it is selected, red dot laser alignment still maintains low energy consumption and low heat dissipation, thus high power version is suitable for long distance dot positioning works effectively.
According to proper use of a qualified glass coated lens and glass window in front of laser beam aperture, whatever kind of working surface it is pointing, this 650nm red laser diode module still keeps work with high transmittance and high photoelectric ability red laser light generation, and converts into increasing brightness and accuracy red dot projection at greater distance of 25 meters and multiple high lighting environments as well. In various industrial precise dot positioning works, red alignment laser dot diameter gets less than 2mm at 10 meters, high positioning accuracy and high stability, unaffected by dust and slight oil contamination as well. Without spending extra time on prior manual or mechanical dot positioning work, it always enables reduced error and improved work efficiency for all precise dot positioning works.
Within the lowest time consumption and the lowest manual labor force input, 650nm red laser diode module always makes sure of simple operation, low maintenance cost, and adapted to low- to mid-range processing equipment. It is compatible with various processing materials such as metals (steel, aluminum), plastics, and wood, requiring no adaptation to special workpiece surfaces.
General applications in industrial processing works:
Metal/Non-metal Processing Positioning: Precise calibration of processing points on CNC lathes, milling machines, and cutting machines
Welding Auxiliary Alignment: Pre-positioning of weld seams and workpiece fitting calibration for laser welding and arc welding
Mold Processing Alignment: Alignment of cavity points and processing path guidance for injection molds and stamping dies
Automated Production Line Positioning: Precise point marking for workpiece gripping and assembly stations on assembly lines
Compact Structure 650nm Red Dot Laser Module Applied For Industrial Machining
Not able to rely on any simple manual dot projecting work, not limited by long distance, high height and other complex working environments etc, a lot of professionals and engineers would prefer to operate a highly intense beam emitted tool of a 650nm red dot laser module. It applies an import 650nm red laser diode and a qualified optic lens inside a durable metal housing tube, connected with an external electric power source. Cooperated with basic heat dissipation design inside a different dimension tube, only if a correct output power made red dot laser alignment makes proper installation or integration with industrial machinery, it projects highly visible and bright red laser light source, and generates ultra clear and precise red dot indication for all raw material processing works conveniently.
Usually 650nm red dot laser module applies an AC/DC adapter as its electric power source, which gets no need to spend extra time on battery change. Employed by an import 650nm red laser diode within 5mW to 100mW and high power range up to 150mW to 500mW, cooperated with a metal heat sink cooling system inside a durable anodized aluminum alloy housing tube, it gets good heat dissipation and ultra stable red laser light and red dot projection as long as 10 hours per day. Either red dot is pointing onto metal or non metal workpiece surface, highly visible red dot alignment is unaffected by ambient light interference.
Being made with a qualified glass coated lens and adjustable focus optic lens in front of beam aperture, 650nm red dot laser module enables high transmittance and high energy density red laser light emission at several miles far away. When it gets special use of adjustable focus optic lens, after its immediate red laser light concentration, it is able to achieve increasing accuracy and brightness red dot projection at a greater distance. Usually red laser dot after its beam focus adjustment can reach as small as 1mm within 5 meters. It also enables high positioning accuracy, error less than 0.1mm. For the most important of all, after integration with APC, ACC intelligent feedback electric driving circuit board, usually red dot laser alignment is resistant to machine tool vibration and electromagnetic interference, assuring continuous operation without light interruption.
Usually 650nm red dot laser module is adapted for machining workshop environments ranging from 10℃ to 60℃, which is temperature and dust resistant, adaptable to humid/dusty conditions. When it adopts ultra compact size tube design of 16mm and 26mm for different output power range, with the assistance of a laser alignment mounting bracket, it can be directly integrated into various machine tools and automated actuators etc. Within the lowest power consumption, low maintenance cost, and no need for frequent replacement or adjustment, red alignment laser gets wide applications for multiple precise machinery processing works.
Applications in industrial machining:
Cutting Positioning: Pre-marking the machining path of milling machines, lathes, and cutting machines, accurately guiding the tool path landing point.
Assembly Calibration: Alignment of parts and mold closing reference marking, improving assembly coaxiality and fitting accuracy.
Welding Aiming: Pre-positioning of weld seams in laser/arc welding, assisting the welding torch in accurately aligning the joint.
Production Line Alignment: Workpiece positioning and conveyor track reference line marking in automated production lines, ensuring precise connection of workstations.
Machine Tool Calibration: Reference point calibration during equipment maintenance, assisting in machine tool accuracy debugging and error correction.
Precise Cross Line Alignment Work with 532nm Green Cross Line Laser Module
What is an efficient job to make ultra clear, precise and fine enough cross line alignment at various work distances? Not able to reply on prior cross line drawing or printing work, a lot of engineers and professionals would prefer to operate a highly bright light emitted tool of a 532nm green cross line laser module. It applies advanced 532nm green DPSS laser tech and a qualified optic lens inside a durable metal housing tube, which also gets basic equipment with thermal emitting system inside a durable housing tube. When green cross laser alignment tool is applied for various scenarios, it projects highly precise cross line positioning and marking works. By outputting a clear green crosshair beam, it provides an intuitive baseline for operations, assisting in rapid alignment, calibration, and contour delineation, reducing human positioning errors.
Compared to any other visible laser devices among all optical spectrum, 532nm green laser light stands among the middle part, which assures the most sensitive color and the brightest green laser light emission from beam aperture. This green cross line laser module applies advanced 532nm green DPSS laser system within 5mW to 200mW. For the most important of all, in order to make long term lasted cross line alignment, it is equipped with a metal heat sink cooling system inside a durable anodized aluminum alloy housing tube, thus 532nm green cross laser alignment gets larger space leaving for tube heat dissipation, and achieves ultra stable and reliable green vertical and horizontal lines generation as long as 10 hours per day. The 532nm green laser light is resulting in significantly higher brightness than red/blue lasers at the same power. Visibility is superior in dim or low-light outdoor environments.
When a qualified glass coated lens is applied inside a durable anodized aluminum alloy housing tube, 532nm green cross line laser module gets different fan angles of 10, 15 and 110 degrees. Owing to its low laser beam divergence of less than 0.3mrad, green cross line maintains sharp crosshair edges, small marking deviation at long distances of 10 to 50 meters, and strong baseline stability. In practical cross line measuring works, only after correct selection of output power and optic lens fan angle, 532nm green alignment laser supports continuous and stable green laser light output, low power consumption, and excellent heat dissipation. It is suitable for industrial conditions from room temperature to -10~60℃, and is resistant to minor vibrations.
Applications:
Industrial Processing: Machining positioning, woodworking cutting marking, sheet metal bending alignment, LED screen assembly calibration.
Architectural Decoration: Wall leveling, ceiling layout, tile laying positioning, door and window installation benchmark marking.
Equipment Support: Automated production line positioning, machine tool processing benchmark lines, and alignment assistance for testing equipment.
Other Scenarios: Laboratory experiment positioning, stage lighting design, and security monitoring area division.
